SCROLL THROUGH THE MEDIA BAR BELOW
OEM PERFORMANCE SERIES


King OEM performance kit custom tuned to provide your Jeep with unparalleled levels of performance and ride quality. Each kit has been subjected to punishing real world testing to develop the optimal damping curve and spring rate for your vehicle. Easy bolt-on installation for stock height or custom kits for trucks running lifted aftermarket suspensions.

Content Separator

Content Separator

Content  Separator

OEM - Jeep Features

Feature 1 1. Lightweight hard anodized 6063 aluminum alloy reservoirs dissipate heat quickly and will not rust due to gas charging contamination. Feature 7 7. The heat treated 6061 aluminum alloy piston has our highly developed port configurations that contribute to the unique damping performance and famous King ride quality.
Feature 2 2. High quality fittings are mated to Aeroquip high pressure hoses which resist abrasion and kinking. Feature 8 8. Wear bands are made from a Rulon composite that offers incredible wear resistance, low deformation under load and high compressive strength. Overlapping end design enhances sealing.
Feature 3 3. Internally threaded top cap design threads over the shock body to enable maximum piston travel inside the shock body. Feature 9 9. Large 3/4" or 7/8" diameter shafts have a minimum tensile strength of 100,000 pounds per square inch. They are hard chromed and micro-polished to a 6 RA finish for extended seal life.
Feature 4 4. 2.5" Shock cylinders are precision bored to within +/- .001, then honed after cadmium plating to remove buildup for a tight piston seal and optimum valving function. Feature 10 10. High strength rod end designed for proper clearance on your application. Steel Teflon lined spherical bearings for smooth articulation and long life with no metal to metal contact.
Feature 5 5. Coilover shocks are machined with our own truncated thread design for ultimate strength and trouble free spring preload and height adjustments. Feature 11 11. Aluminum components and vehicle specific mounts are machined from aircraft quality billet. Front and rear kits all include all necessary vehicle specific mounting brackets and hardware along with detailed installation instructions. Technical support, if needed, is only a phone call or email away.
Feature 5 6. Pinch bolt coil adjuster nut offers superior clamping force to retain your coil preload adjustments without crushing the threads like set screw style collars do. 12. Internal reservoir allows easy bolt-on installation and guards against shock fade during severe use.

Content Separator

OEM - Jeep Series

Part# Description Type Details Weight Compressed length Extended length
20001-206 2.0 Jeep JK 07 + 0-2" Lift Front Shocks

15.946

25.204

20001-207 2.0 Jeep JK 07 + 0-2" Lift Rear Shocks

16.397

25.322

20001-166 2.0 Jeep JK 07 + 3"-5" Lift Front Shocks

17.008

27.328

20001-167 2.0 Jeep JK 07 + 3"-5" Lift Rear Shocks

17.472

27.097

20001-204 2.0 Jeep JK 07 + 6" Lift Front Shocks

19.765

32.042

20001-205 2.0 Jeep JK 07 + 6" Lift Rear Shocks

19.554

31.302


25001-180 Jeep JK 07 + 0-2" Lift Front Shocks

15.831

25.902

25001-181 Jeep JK 07 + 0-2" Lift Rear Shocks

16.188

26.28

25001-223 Jeep JK 07 + 3"-5" Lift Front Shocks

16.893

27.27

25001-224 Jeep JK 07 + 3"-5" Lift Rear Shocks

17.263

28.14

25001-284 Jeep JK 07 + 6" Lift Front Shocks

18.65

31.043

25001-285 Jeep JK 07 + 6" Lift Rear Shocks

19.563

32.28


25001-180A Jeep JK 07 + 0-2" Lift Adjustable Front Shocks

15.831

25.902

25001-181A Jeep JK 07 + 0-2" Lift Adjustable Rear Shocks

16.188

26.28

25001-223A Jeep JK 07 + 3"-5" Lift Adjustable Front Shocks

16.893

27.27

25001-224A Jeep JK 07 + 3"-5" Lift Adjustable Rear Shocks

17.263

28.14

25001-284A Jeep JK 07 + 6" Lift Adjustable Front Shocks

18.65

31.043

25001-285A Jeep JK 07 + 6" Lift Adjustable Rear Shocks

19.563

32.28


25001-160 Jeep TJ 97-06 0-2" Lift Front Shocks

15.003

23.103

25001-161 Jeep TJ 97-06 0-2" Lift Rear Shocks

13.671

21.016

25001-176 Jeep TJ 97-06 3"-5" Lift Front Shocks

15.803

24.903

25001-177 Jeep TJ 97-06 3"-5" Lift Rear Shocks

14.671

23.016

25001-286 Jeep TJ 97-06 6" Lift Front Shocks

17.83

28.457

25001-287 Jeep TJ 97-06 6" Lift Rear Shocks

16.434

26.276


25001-160A Jeep TJ 96-06 0-2" Lift Adjustable Front Shocks

15.003

23.103

25001-161A Jeep TJ 96-06 0-2" Lift Adjustable Rear Shocks

13.671

21.016

25001-176A Jeep TJ 96-06 3-5" Lift Adjustable Front Shocks

15.803

24.903

25001-177A Jeep TJ 96-06 3-5" Lift Adjustable Rear Shocks

14.671

23.016

25001-286A Jeep TJ 96-06 6" Lift Adjustable Front Shocks

17.83

28.457

25001-287A Jeep TJ 96-06 6" Lift Adjustable Rear Shocks

16.434

26.276


25001-162 Jeep WK Grand Cherokee 05-10 Front Coilover

48

16.091

20.888

25001-162A Jeep WK Grand Cherokee 05-10 Front Coilover Comp. Adj.

50

16.091

20.888

25001-163 Jeep WK Grand Cherokee 05-10 Front Coilover IFP

45

16.091

20.888

25001-166 Jeep WK Grand Cherokee 05-10 Rear Shocks

26

15.251

24.593

25001-166A Jeep WK Grand Cherokee 05-10 Rear Shocks Comp. Adj.

27

15.251

24.593
