UTV

King Shocks custom tuned, UTV performance shock kit gives your Polaris Ranger or RZR unparalleled levels of performance and ride quality. Each side x side shock kit was developed with punishing real world testing to develop the optimal damping curve and spring rate. UTV shock kits available for stock height or long travel aftermarket suspensions provide easy bolt-on installation and adjustable ride height.

                                                        UTV Flyer 2015

Content Separator

Content Separator

UTV Performance Series - Polaris Image

UTV Performance Series - Polaris Feature List

Content Separator

UTV Performance Series - Polaris Features

Feature 1 1. Beautifully anodized aircraft quality billet aluminum construction.. Feature 7 7. Large 3/4" diameter shafts have a minimum tensile strength of 100,000 pounds per square inch. They are hard chromed and micro-polished to a 6 RA finish for extended seal life.
Feature 2 2. Clearly marked, ergonomic knob design is easy to use even while wearing gloves. Feature 8 8. Shock cylinders are precision bored to within +/- .001, then honed after cadmium plating to remove buildup for a tight piston seal and optimum valving function.
Feature 3 3. Individual detents make each click of adjustment easy to feel while turning. Each of the twenty levels of adjustment offers precise compression damping control ranging from very soft to very firm. Feature 9 9. Bolt on installation available in stock lengths or extended versions for long travel suspensions.
Feature 5 4. Wide range compression adjuster can be retro-fitted to existing King Shocks. Feature 10 10. Integrated piggyback style mounted light weight hard anodized 6063 aluminum alloy reservoirs dissipate heat quickly and will not rust due to gas charging contamination.
Feature 5 5. Reservoir mount bolts securely to the shock and includes a quad sealed fluid transfer tube. Feature 11 11. Urethane foam bump stop included to cushion when bottoming.
Feature 6 6. Machined with our own truncated thread design for ultimate strength and trouble free spring preload and ride height adjustments. Feature 12 12. Aluminum components are machined from aircraft quality billet. Steel Teflon lined spherical bearings for smooth articulation and long life with no metal to metal contact.

Content Separator

UTV Performance Series - Polaris Series

POLARIS

Part# Description Type Details Weight Compressed length Extended length
20001-110 RZR 800 Front Coil Over   30 11.451 16.754
20001-117 RZR Sway Bar Link Kit *Req w/Front Shocks
20001-111 RZR 800 Rear Coil Over   30 12.585 19.004
20001-110A RZR 800 Front Coil Over Compression Adjuster 30 11.451 16.754
20001-111A RZR 800 Rear Coil Over Compression Adjuster 30 12.585 19.004

20001-118 RZR 800-S Front Coil Over   30 13.789 19.417
20001-119 RZR 800-S Rear Coil Over   30 14.872 21.497
25001-339A RZR 900S 2.5 Front Piggyback Coil Over Compression Adjuster
25001-340A RZR 900S 2.5 Rear Piggyback Coil Over Compression Adjuster
20001-118A RZR 800-S Front Coil Over Compression Adjuster 30 13.789 19.417
20001-119A RZR 800-S Rear Coil Over Compression Adjuster 30 14.872 21.497

20001-126A RZR-900XP/XP4, 2.0 Front Coil Over Compression Adjuster 30 15.507 23.308
20001-127A RZR-900XP/XP4, 2.0 Rear Coil Over Compression Adjuster 30 14.607 22.661

25001-126A RZR-900XP/XP4, 2.5 Front Coil Over Compression Adjuster 36 15.639 23.526
25001-127A RZR-900XP/XP4, 2.5 Rear Coil Over Compression Adjuster 36 15.889 22.776

25700-323A RZR XP 1000 2.5 Front Coil Over Compression Adjuster   16.750 25.125
25700-324A RZR XP 1000 2.5 Rear Coil Over Compression Adjuster   22.188 34.500
25700-324AF RZR XP 1000 2/4 2.5 Rear Coil Over Compression Adjuster w/ Finned Reservoir   22.188 34.500
33700-324AF RZR XP 1000 2/4 Seat 3.0 W/Finned Reservoir Rear Coil Over Compression Adjuster w/ Finned Reservoir
